Double Coating Double Baking Steel/Aluminum Coil Color Coating Line for PPGI/PPGL

Overview

Basic Info.

Model NO.	CCL-009
Coating	Coil Coating
Substrate	Steel
Certification	ISO
Condition	New
Coating Material	Steel/Aluminum/Gi/Gl
Control System	PLC+Touch Screen Automatic
Install Location	Customer Location
Kinds of Coating	Liquid Coating
Equipment Name	Electrical Transmission System
Color	Customer′requirement
Used for	Household Appliance
Advantage	Environmental-Protection
Ater-Sales Service Provided	Online Video Technical Support
Process Speed	25-180m/Min
Coating Color	Customer′requirement
Usage	Appliance Paint
Thickness of Strip Steel	0.12-1.5mm
Outer Diameter of Steel Coil	φ;800-2000mm
Width of Strip Steel	600-1650mm
Transport Package	Standard Seaworthy Package
Specification	Customized
Trademark	Reachfly
Origin	China
HS Code	8479819000
Production Capacity	20sets/Year

Packaging & Delivery

Package Size 15.00cm * 10.00cm * 0.20cm Package Gross Weight 0.500kg

Product Description

Double Coating Double Baking Steel/Aluminum Coil Color Coating Line for PPGI/PPGL

The color coating line is a complete sets of production equipment to degrease and passivate the surface of the metal plate, and then coat the surface with multiple layers of organic paint by continuous roller coating, and then overprint patterns of various colors to form a new type of functional plate. The color coating plate is mainly based on cold rolled plate, galvanized / AL-ZN steel plate and aluminum alloy plate. This kind of plate has advantages of corrosion resistance and decoration, as well as directly providing raw material for construction industry, automobile manufacturing, electric and others.

Color Coated Steel Production Line
Material of base plate	Steel coils (CR, GI, GL, SS), Aluminum coils
Width of strip steel	650-1650mm
Thickness of strip steel	0.15-2.0mm
Outer diameter of steel coil	Φ800-2000mm
Process speed	max 200m/min
Thickness of coating	5-25μm for the single-layer dry film on the front (or customized)5-15μm for the single-layer dry film on the back (or customized )
Thickness of printing layer	≤1μm (oil link or polyester)
Production capacity	max 200,000 T/Year

1. Line Type: one coating and one baking, two coating and two baking, three coating and three baking.2. Coating Type: epoxy resin, polyurethane, polyester, polypropylene, polyvinyl fluoride, silicon modified polyester3. Chemical Coater: dual-head two-roll type (used in prime coating), three-roll type (used in finish coating front side), two-roll type (used in finish coating back side).4. Catalytic Incineration System: RCO, RTO, DTO5. We also provide Pattern Printing System to produce pattern color coated steel, like the wood grain, brick grain, stone grain, marble grain and so on.Packaging & Shipping1. Export standard wooden cases packed in suitable container.2. Cooperate with reliable shipping company to ensure the delivery time.3. Customized Packing is allowed.Company Profile

QINGZHOU REACHFLY ENVIRONMENT TECHNOLOGY CO., LTD.
We are manufacturer of metal strip coils processing equipment.We can supply and install (turnkey project):1.Continuous Hot Dip Galvanizing / AL-ZN Coating Line - CGL / HDG2.Continuous Coils Color Coating Line - CCL3.Slitting Line4.Tension leveler Line5.Skinpass Mill Line
Our Advantage:1) Standardized workshop of total 360,000 square meters.2) Professional technical team with more than 10 years experience, We can produce different product with different kinds of requirements and work out reasonable flow chart as per customers' requirements to save space.3) Sufficient stock of spare parts ensures the timely delivery and supply of spare parts.

FAQ

1. Do you offer custom service?Of course, most of our machines are built according to customers specifications, using top brand name components. 2. How to ensure the quality?1)In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years. 2)Each component before assembly needs strictly control by inspecting personnel. 3)Each assembly is in charged by a master who has working experience for more than 5 years.4)After all the equipment are completed, we will assembling all the machines and run parts testing for at least 12 hours to ensure the stable running in customers' factory.3.Do you provide after-sales service?1)After finish the production, we will debug the production line, take photos, videos and send them to customers via mail or instant tools.2)After the commissioning, we will package the equipment by standard export package for shipment. 3)We will arrange our engineers to customers' factory to do the installation and training. 4)Engineers, sales managers and after-sales service manager will form a after-sales team, online and off line, to follow the customers' project.

You are welcome to visit our factory at any time!
